Fig. 1.
HST WFPC2
V image of
SBS 0335-052 showing the high surface brightness super-star clusters.
At a distance of 54.3 Mpc, 1 arcsec corresponds to a linear size of
263 pc
Fig. 2.
(V-I) color vs. distance from the brightest super-star cluster at the
SE tip of SBS 0335-052.
The color gets redder with increasing distance
Fig. 3.
(V-I) color map of SBS 0335-052.
Blue is dark, red is light.
The dust patches on top of the super-star clusters are clearly seen
Fig. 4.
Same
V image as in
Fig. 1, with
the contrast adjusted to show the low surface brightness underlying component
of SBS 0335-052.
The supershell delineating the large supernova cavity is clearly seen
Fig. 5
(U-B) color profile (labeled E) of SBS 0335-052.
The color is very blue and the profile flat
Fig. 6.
HST GHRS spectrum of SBS 0335-052
around the Lyα line.
A strong damped Lyα absorption is seen along with several heavy element
interstellar absorption lines
Fig. 7.
HST WFPC2
I image of
SBS 1415+437.
The shape is cometary-like.
A bright supergiant H
II region at the SW end, resolved
stars in the body of the galaxy and unresolved diffuse stellar emission can
be seen.
The different regions used for stellar population color-magnitude diagram
analysis are marked
Fig. 8.
Color-magnitude diagrams of stellar populations in the different regions of
SBS 1415+437 as defined in
Fig. 7.
There is a systematic age increase from region I to region VI,
implying propagating star formation from the NE to the SW
Fig. 9.
MMT spectrum of region V (see
Fig. 7) of SBS 1415+437.
The upper panel shows the spectrum uncorrected for extinction, while the lower
panel shows the same spectrum corrected for extinction.
The best-fit model gives an age between 30 and 100 Myr
Fig. 10.
Ne/O, Si/O, S/O and Ar/O abundance ratios vs. O abundance for the BCD sample
of Izotov & Thuan (1998c).
The solid lines show the ratios predicted by models of nucleosynthesis
(Woosley & Weaver 1995)
Fig. 11.
C/O, N/O and Fe/O abundance ratios vs. O abundance for the BCD sample of
Izotov & Thuan (1998c).
The solid lines for C/O show the ratios predicted by models of nucleosynthesis
(Woosley & Weaver 1995) for high-mass stars.
The dashed lines represent the predicted ratio for the contribution of both
high- and intermediate-mass stars
Fig. 12.
HST GHRS spectrum of T1214-277 around
the Lyα line.
There is Lyα emission and a N
V λ1240 line
with a conspicuous P Cygni profile
Fig. 13.
Spectrum of SBS 0335-052 showing the P Cygni profiles of the Si
λ1394 and λ1403 interstellar absorption lines
Fig. 14.
Linear regressions of (a) the helium mass fraction Y vs. oxygen
abundance and (b) the helium mass fraction Y vs. nitrogen abundance for
the sample of 45 H II regions in BCDs of Izotov & Thuan
(1998b).
1 σ alternatives are shown by dashed lines
Fig. 15.
The abundances of c) 4He; d) D and e) 7Li as a function
of η10 ≡ 1010η, where η is the
baryon-to-photon number ratio, as given by the standard hot big bang
nucleosynthesis model
